Farmer-Helper FH-BX62R 7” Hydraulic Feed Wood Chipper
Feed is:
Hydraulic Feed
Powered By:
Tractor PTO
25- 45 HP
Playlist
6:50
2:37
Who is Farmer-Helper?
Farmer Helper Machinery Co., Ltd (FHM) was established in 2009. The factory area is more than 20,000 square meters and houses 4 Metal laser cutting machines and more than 80 processing machines.
FHM manufactures a full range of high-quality implements for small to medium-sized tractor owners across the world. Farmer’s Helper has become an integral manufacturing premise for agricultural machines. Our team’s priority is customer success and satisfaction. We constantly improve our machines to meet customer demands and expectations.
Key Features:
Designed with a 30” 205 lbs. Flywheel with 4 reversible Chipping Blades.
Blowing force is maximized with air intake vents on the side of the chipper. Air enters through the vents and powers the chips out the chute up to 20 feet.
Behind the blades are blower paddles with integrated twig breakers designed for greater output force and smaller chips existing the machine. This provides more consistent chip size and allows you to propel the chips further.
The feed chute easily folds up for storage, minimizing the storage space for the machine while still assembled.
Easily control where you want the chips with the double adjustable exit chute. The chute swivels 300 degrees and the top deflector adjusts the distance.
The Machine comes with a 6 spline Series 5 80cm (31.5”) PTO Shaft.
This machine is capable of chipping material up to 7” in diameter.
For full capability, it is recommended for tractors with 30 to 75 HP.
Farmer-Helper Hydraulic Feed Wood Chipper is a heavy-duty and efficient machine, which has the capacity to chip large branches and debris. Its heavy-duty extra-large rotor and reversible chipping blades can chip 7″ diameter branches or 6.5 x 12″ slabs. These precision-ground, hardened tool steel blades provide a sharp, long-lasting cutting edge, which delivers efficient chipping operation.
The chipper is also equipped with twig breaker blower paddles that avoid clogging and maintain uniform chip size. The double adjustable exit chute swivels 270 degrees, enabling users to direct where the chips go and making it easy to guide the chip flow wherever needed.
The hydraulic feed hopper with forward, or reverse speed control feature ensures simple and efficient chipping. By enabling operators to regulate the flow of materials through the chipper, the Farmer-Helper Hydraulic Feed Wood Chipper ensures optimum performance.
The driveline that is provided makes it simple and convenient to attach the chipper to a tractor, allowing one to hook up and work in a short while. The Farmer-Helper Hydraulic Feed Wood Chipper, being sturdily built and simple to operate, is an excellent choice for property owners and professionals who need a high-performance and reliable wood chipper.
| Model | FH-BX62R |
| Maximum Chipping Capacity | 6.5” x 12” Material |
| Maximum Diameter | 7” diameter |
| Min. Operation PTO Horsepower | 25 HP |
| Max Capacity PTO Horsepower | 45 HP |
| No. of Blades | 4 Blades |
| Rotor Size & Thickness | 30” dia. x 3/4” |
| Flywheel Weight | 205 lbs |
| Feeding System | Hydraulic Feed |
| Hopper Folded | 50” L x 52” W x 74” H |
| Hopper Opening | 25” x 25” |
| Mounting System | 3 point Hitch Cat I |
| Discharge Rotation | 270° (facing operator blocked) |
| Discharge Height | 80” |
| PTO Drive Line | Series 05 Shear Bolt Driveline |
| Net Weight | 990 lbs / 449 kg |
| Gross Weight | 1070 lbs / 485 kg |
