Farmer-Helper FH-EFGC Heavy Duty MOWER
SKU: FH-EFGC105, FH-EFGC125, FH-EFGC155, FH-EFGC175, FH-EFGC195
Working Width
41″ – 77″
Powered By:
Tractor PTO
20- 65 HP
Comes with 27 oz Blades
Hydraulic Offset Available
Suitable for:
Brush up to 3″ thick
Playlist
-
41″ Heavy Duty Flail Mower, FH-EFGC105
$2,350.00In stock
Add to cart -
48″ Cut Heavy Duty Hydraulic Offset Flail Mower, FH-EFGCH125KIT
$2,880.00In stock
Add to cart -
48″ Heavy Duty Flail Mower, FH-EFGC125
$2,430.00In stock
Add to cart -
60″ Cut Heavy Duty Hydraulic Offset Flail Mower, FH-EFGCH155KKIT
$3,235.00In stock
Add to cart -
60″ Heavy Duty Flail Mower, FH-EFGC155
$2,785.00In stock
Add to cart -
68″ Cut Heavy Duty Hydraulic Offset Flail Mower, FH-EFGCH175KITT
$3,345.00In stock
Add to cart -
68″ Heavy Duty Flail Mower, FH-EFGC175
$2,895.00In stock
Add to cart -
77″ Cut Heavy Duty Flail Mower, FH-EFGC195
$3,040.00In stock
Add to cart -
77″ Cut Heavy Duty Hydraulic Offset Flail Mower, FH-EFGCH195KIT
$3,480.00In stock
Add to cart
Who is Farmer-Helper?
Farmer Helper Machinery Co., Ltd (FHM) was established in 2009. The factory area is more than 20,000 square meters and houses 4 Metal laser cutting machines and more than 80 processing machines.
FHM manufactures a full range of high-quality implements for small to medium-sized tractor owners across the world. Farmer’s Helper has become an integral manufacturing premise for agricultural machines. Our team’s priority is customer success and satisfaction. We constantly improve our machines to meet customer demands and expectations.
| Spec | FH-EFGC105 |
| Working Width | 41” |
| Overall Width | 47” |
| Min. HP Req. | 20 HP |
| Hitch | Cat. I |
| Gear Box Rating | 65 HP |
| Distance Right of Center Mount | 19 inches or 23.25 inches |
| Std Hammer Blades | 16 Hammer Blades |
| Housing Thickness | 4mm |
| Side Plate Thickness | 1/4” |
| Rotor Dia. | 4” |
| Rotor Shaft Dia. | 4 1/2” |
| Blade Swing | 14.5” |
| No. of Belts | 2 Belts |
| 3pt Conn. Width Driveline Type | Series 4 Quick Connect Shear Bolt, 6-Spline |
| Weight | 540 lbs |
| Crated Weight | 570 lbs |
| Spec | FH-EFGC125 |
| Working Width | 48” |
| Overall Width | 54” |
| Min. HP Req. | 22 HP |
| Hitch | Cat. I |
| Gear Box Rating | 65 HP |
| Distance Right of Center Mount | 23.50 inches or 27.75 inches |
| Std Hammer Blades | 20 Hammer Blades |
| Housing Thickness | 4mm |
| Side Plate Thickness | 1/4” |
| Rotor Dia. | 4” |
| Rotor Shaft Dia. | 4 1/2” |
| Blade Swing | 14.5” |
| No. of Belts | 2 Belts |
| 3pt Conn. Width Driveline Type | Series 4 Quick Connect Shear Bolt, 6-Spline |
| Weight | 600 lbs |
| Crated Weight | 635 lbs |
| Spec | FH-EFGC155 |
| Working Width | 60” |
| Overall Width | 67” |
| Min. HP Req. | 25 HP |
| Hitch | Cat. I |
| Gear Box Rating | 65 HP |
| Distance Right of Center Mount | 35.25 inches or 39.50 inches |
| Std Hammer Blades | 24 Hammer Blades |
| Housing Thickness | 4mm |
| Side Plate Thickness | 1/4” |
| Rotor Dia. | 4” |
| Rotor Shaft Dia. | 4 1/2” |
| Blade Swing | 14.5” |
| No. of Belts | 3 Belts |
| 3pt Conn. Width Driveline Type | Series 5 Quick Connect Shear Bolt, 6-Spline |
| Weight | 720 lbs |
| Crated Weight | 755 lbs |
| Spec | FH-EFGC175 |
| Working Width | 68” |
| Overall Width | 75” |
| Min. HP Req. | 30 HP |
| Hitch | Cat. I |
| Gear Box Rating | 65 HP |
| Distance Right of Center Mount | 43.25 inches or 47,50 inches |
| Std Hammer Blades | 28 Hammer Blades |
| Housing Thickness | 4mm |
| Side Plate Thickness | 1/4” |
| Rotor Dia. | 4” |
| Rotor Shaft Dia. | 4 1/2” |
| Blade Swing | 14.5” |
| No. of Belts | 4 Belts |
| 3pt Conn. Width Driveline Type | Series 5 Quick Connect Shear Bolt, 6-Spline |
| Weight | 740 lbs |
| Crated Weight | 790 lbs |
| Spec | FH-EFGC195 |
| Working Width | 77” |
| Overall Width | 83” |
| Min. HP Req. | 35 HP |
| Hitch | Cat. I |
| Gear Box Rating | 65 HP |
| Distance Right of Center Mount | 47.25 inches or 51.50 inches |
| Std Hammer Blades | 32 Hammer Blades |
| Housing Thickness | 4mm |
| Side Plate Thickness | 1/4” |
| Rotor Dia. | 4” |
| Rotor Shaft Dia. | 4 1/2” |
| Blade Swing | 14.5” |
| No. of Belts | 4 Belts |
| 3pt Conn. Width Driveline Type | Series 5 Quick Connect Shear Bolt, 6-Spline |
| Weight | 790 lbs |
| Crated Weight | 830 lbs |
Description for flail mower:
The Farmer-Helper EFGC Series (Heavy Duty) Flail Mower is an option if you are working on grass or brush. Ideal for an orchard, nursery, vineyard, in the greenhouse or for gardening. With its fast blade tip speed and interchangeable blades, it is perfect for your grounds keeping tasks. If you need to maintain more dense areas, install the hammer blades and you will be able to cut and mulch wooded material up to 3 inches in diameter. This model is great for acreage larger than 15 acres.
Flail Mowers are useful for jobs where you are cutting grass on the uneven ground, high grass, weeds, brush, and small saplings. A flail mower doesn’t throw grass, instead, it cuts finely and leaves the cuttings on the ground where it was cut making it an excellent choice for those places where you could cause damage by throwing debris. Highway mowing and park maintenance often use flail mowers because they are less likely to throw objects during cutting.
Key Features:
- Comes with hammer blades with precise blade overlap
- Multiple drive belts assure power to the blades
- Under Deck Clump Busters
- Standard 3-Pt category I hitch mount
- Shear Bolt PTO Shaft for Standard 1-3/8” 6-Spline PTO
- PTO driveline included free of charge
- Adjustable finished cutting height (both rear roller & skids)
- Balanced rotor and shaft
- Powder coat paint finish
- Optional hydraulic offset kit
Details:
Overall Width: The Farmer-Helper EFGC series has an overall width of 47″ to 83″ depending on the size of the unit.
Cutting Width: The Farmer-Helper EFGC series has a cutting width of 41″ to 77″ depending on the size of the unit.
Weight: The Farmer-Helper EFGC series has a weight of 540 lbs to 790 lbs depending on the size of the unit.
HP Requirements at PTO: The Farmer-Helper EFGC series requires 20 – 65 PTO horsepower depending on the size of the unit.
Cutting Height: The Farmer-Helper EFGC series has a 0″ – 6″ Adjustable to meet various height requirements
Housing Material Thickness: The Farmer-Helper EFGC series has a housing thickness of 4mm.
Side Plate Thickness: The Farmer-Helper EFGC series has a side plate thickness of 1/4″.
Blade Type: The Farmer-Helper EFGC series uses a standard hammer blade. Each hammer blade weighs 1 lb. 11 oz made of cast steel (cast steel is much more durable than cast iron). Use the hammer blades for clearing saplings (3″ diameter or less), and for grasses.
Number of Blades: The Farmer-Helper EFGC series uses 16 – 32 hammer blades, depending on the size of the unit.
Precision Blade Overlap: On the Farmer-Helper EFGC series the blades are staggered precisely with no gap in the mowing area. Blade overlap is important to achieve an even cutting result.
Rotor Rotation – Reverse: The rotor spins in the opposite direction as the wheels of the tractor when traveling forward. This allows the blades to shear the material as it is folded forward by the mowers. The material is then thrown up and over the rotor.
Rotor Tube Diameter: 4″- Heavy-duty steel tubing for long life.
Balanced Rotor Tube: The rotor tube is balanced to reduce vibration and ensures that the mower runs smooth, and reduces wear on the bearings.
Rotor Swing Diameter: 14 1/2″ Large swing so that the blades build required inertia.
Hitch Type: Category 1 standard 3-point.
Offset From Center Mount: This feature allows for an offset from center to the right of the tractor. This feature is helpful for mowing around fences, buildings; walkways etc. From the center of the PTO, the mower extends 19″ to 47 1/4″ depending on the size of the unit.
Drive Belts: The Farmer-Helper EFGC series uses 2 – 4 belts, depending on the size of the unit.
Gearbox Rating: Up to 65 hp. Heavy duty proved oil bath gearbox for long life.
Driveline / PTO Shaft: Shear Bolt PTO Shaft for Standard 1-3/8” 6-Spline PTO
Finish: Baked-on powder coat, powder coat is superior to paint.
Warranty: 2-year parts warranty with an optional 2-year extension.
Support Before and After the Sale: At Betstco our service department is staffed with professional technicians that inspect each machine before it is shipped. This ensures that you get a trouble-free machine from the get-go. When you need technical help or parts, our courteous staff can help you get what you need from our fully stocked warehouse. We keep a full line of replacement parts, and we can ship parts within 24 hours.
Submit your review | |
Just got my mower the other day. So far I have used it about an hour. So far so good. I found it was well packed in the welded steel cage. Fortunately I had a grinder with cutoff wheel. Although I found the videos online and the abundant instructions, it was still difficult to tell how the uprights should be attached to the mower body. I see that some improvements have been made in response to previous comments; the stand now bolts into a threaded reinforced area rather than trying to get the nuts up behind the leading edge guards. And there is a hole in the belt cover to grease the bearing. My biggest complaint about 5ge instructions is not knowing how much gear oil is needed, I found that I needed about 1 liter, not a gallon jug shown in one of the pictures. My most serious complaint is about the black plastic the pto shield. It doesn’t have enough flair for man sized hands to get in there and squeeze the pto lock mechanism. I wish it has a flip up metal cover similar to the tractor. Alternately maybe a pto shaft with collar locks would be easier. Honestly Inthink Inspent more time fighting the pto shaft than mowing. However the mowing I did do was really good. I have pasture that has not been mowed for several years, and is now sprouting Douglas fir and alders along with Scott’s broom and blackberry. So far it’s made easy work of the vegetation. Once I get a hang of the pto shaft, I won’t dread taking to mower off to use another implement.
I have twenty acres or so that have become very heavily overgrown. I bought the EFGC155 with hammer blades to beat the brush into nothingness. I've never had a flail mower before, so I immediately burned up a set of belts. I now always keep a spare set handy. Now that I have the hang of the mower, I have been clearing like a demon! I basically just drive into the brush with my blade down low to push everything over, and the mower grinds it into barkdust. I am very happy with this flail mower. I'm operating it on a 35 hp tractor with no difficulties.
Very impressed so far, i performed a torque audit and a bearing break-in procedure before putting any serious load on the machine, It cut with ease, actually much quieter then i was anticipating, this unit is a beast. With proper maintenance, this unit will outlast me and my son's son/daughter.
Works fantastic, gives a decent finish cut and grinds up everything, brush, branches and bark.
Great price. Fast shipping. Quality workmanship. Very pleased. Highly reccomend.
I was suprised to see how heavy duty this mower is built. Its a very nice machine and will last a very long time. Do not be afraid to buy this product!
