BC-XE Gear Drive L-Blade Tiller

Made in India

SKU: BC-XE36, BC-XE42, BC-XE48, BC-XE60

The Manual

2 year warranty with optional 4 years

working width

Working Width

36″ – 60″

powered by tractor pto power

Powered By:

Tractor PTO
15- 40 HP

The well-designed Xeos series tiger rotary tiller is single speed gear drive implement and suitable for compact and sub-compact tractors from 15 to 40 HP. Widely applicable for soil preparation in Nurseries, Vineyards, Orchards, and Hobby Farms. Each flange has 6 heat-treated blades, fitted in a special arrangement that reduces the load on the tractor and gives fine finish performance. Standard attachment front safety guard, clutch PTO joint, and tool kit

Key Features

* Available in four models XE36, XE42, XE48 and XE60
* Suitable for 15 to 40 HP tractor
*6 Blades on each flange
*Available in “L” shape blade, 60 mm x 6 mm
*50 Hp and 540 RPM Single Speed gear drive model
* 17″ rotor swing diameter

Model

XE 36

XE 42

XE 48

XE 60

Standard Tine Rotation

Yes

Yes

Yes

Yes

Working Width

36”

42”

50″

60”

Overall Width

40”

47”

55″

65″

Min-Max HP

15-18 HP

20-30 HP

20-35 HP

25-40 HP

3 Point Hitch

Cat l

Cat l

Cat l

Cat I

Offsetable Distance from Center

Centered

Gear Box Maximum PTO HP

50 HP, 540 RPM, SINGLE SPEED

Number of Flanges

4

5

6

7

Number of L shaped Tines

24

30

36

42

Maintenance free oil bath transmission

Gear Drive Transmission

Rotor swing dia

17″

17″

17″

17″

Adjustable tilling depth

2-6″

2-6″

2-6″

2-6″

PTO slip clutch

Yes

Yes

Yes

Yes

540 rpm pto drive line

Series 4 (T4-800)

Weight

342 lbs

375 lbs

408 lbs

452 lbs

Crated weight

402 lbs

446 lbs

480 lbs

527 lbs
